IT’S HERE: AN INNOVATIVE NEW AODD PUMP WITH THE X FACTOR FOR CONVENIENCE, EFFICIENCY & VERSATILITY

SANDPIPER pumps continue to advance in performance and reliability. Meet the new SANDPIPER EvolutionX 2" pump, an enhanced addition to our proven EvolutionX pump line.

This innovative air operated double diaphragm pump design is the culmination of over 55 years of industry-leading research, development and engineering in pump & fluid dynamics. The EvolutionX represents the pinnacle of performance, efficiency and serviceability. Watch the video below to learn more.

HOW YOU WILL BENEFIT FROM THE SANDPIPER EVOLUTIONX AODD PUMP

Enhanced Serviceability & Convenience

• Reduced service time – EvolutionX takes, on average, five minutes to service the air distribution system compared to 45 minutes on average for other AODD pumps.
• Improved Mobility – 28% lighter weight for improved mobility over our prior S20 model (Polypropylene models).
• Serviceability – All of the wet side nuts and bolts are the same size & length.
• Accessibility – You can access air side components by removing only four bolts revealing an easily removable cartridge-style main air valve and pilot valve assembly (US Patent 12516663).
• Improved Stability for Increased Safety – We have added “stand-off feet” to the inner chambers to stabilize the pump on the workbench during disassembly.

Superior Performance & Efficiency

Improve overall efficiency and safety during operation while decreasing operating costs due to:

• Lowest Energy Use:
  • Up to 73% greater efficiency than leading competitors.
  • Achieves an incredible 22% average increase in air efficiency throughout the entire curve over our prior S20 model.
• Highest Flow Rates:
  • Up to 30% higher flow than leading competitors.
  • 25% higher flow rate than our prior S20 model it is replacing.
• Highest Suction Lift:
  • Over a 44% increase in maximum suction lift over prior S20 model.
  • Up to a 61% higher suction lift capability compared to leading competitors.
• Ability to Pass Largest Solids:
  • Easily passes up to .66” solids.
  • Able to pass up to 75% larger solids than the next nearest leading competitor.
• Highest Displacement per Stroke:
  • Up to 152% greater displacement per stroke than leading competitors resulting in significantly slower stroke rates compared to competitors to move the same amount of fluid. This provides significantly longer service item life (balls, seats, diaphragms, etc).

Increased Versatility

Meet countless configuration and application needs with interchangeable components, featuring:

• Material:
  • Durable, non-metallic construction rated for operation up to 125 psi with ATEX versions available.
• Numerous porting options:

  • The standard EvolutionX configuration features a versatile 3-piece manifold with a universal ANSI/DIN flanged connection.  Users can quickly adjust the discharge outlet for porting in multiple directions. Other porting options include a single-piece end-ported manifold.
• Versatile Mounting:
  • The mounting feet are extremely versatile and fit existing SANDPIPER pumps and multiple other manufacturers’ dimensions.

*Efficiency as measured by gallons pumped per cubic foot of air consumed.

**Comparisons made using published performance data at max flow rate and using comparable materials unless otherwise noted.
